Варианты
- Liore et Olivier - CL.10 - 1932 - Франция
- Westland-Lepere - CL-20 - 1935 - Великобритания
Фотографии
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
The completed CL.20 at Hanworth during the summer of 1935.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
The completed Westland CL.20 at Hanworth early in 1935. It was doped silver overall with black trim and lettering.
-
Flight 1935-12 / Flight
SIDE-BY-SIDE AUTOGIRO SEATING: It is now possible to publish a photograph of the Westland-Lepere Autogiro, which is of the direct-control type and has a very wide wheel track to ensure stability on the ground. The engine is a 90 h.p. Pobjoy Niagara. The large expanse of transparent covering gives an excellent view from the cabin.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
The CL.20, in red primer, photographed at Hanworth on February 15, 1935 during taxying trials.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
The completed Westland CL.20 at Hanworth early in 1935. It was doped silver overall with black trim and lettering.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
The same aircraft photographed at Hanworth, still in primer paint but with wheel spats.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
Instrumentation on the CL.20 was sparse - note the fuel tank immediately behind the oval instrument panel.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
This Clark cutaway drawing appeared in The Aeroplane for December 18, 1935, when first details of the CL.20 were published. Contrary to the drawing, the autogiro had no rudders. The horizontal tailplane was built in two halves; on one the aerofoil was inverted and negative incidence-given to provide negative lift, and the other was set with positive incidence - this compensated for propeller torque.
-
Aeroplane Monthly 1989-02 / R.Riding - Westland CL.20 /British prewar lightplanes/ (4)
This view of the CL.20 clearly shows the cabin glazing, which gave very good all-round vision for the occupants. The engine is a 90 h.p. Pobjoy S radial.
