Фотографии
-
Регистрационный номер: XX153 [2] The first development Lynx in Army utility configuration demonstrates its manoeuvrability. This airframe, XX153, was also used during 1972 to set speed records over a straight line and closed circuit
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Регистрационный номер: XX510 [2] The Naval trials Lynx XX510 has been used for several series of operations aboard various ships including HMS Sheffield
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
The Naval trials Lynx XX510 has been used for several series of operations aboard various ships including the French frigate Tourville. For the latter trials, it sported Aeronavale markings on one side of the fuselage, retaining RN markings on the other side.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
The Naval trials Lynx XX510 has been used for several series of operations aboard various ships including the French frigate Tourville. For the latter trials, it sported Aeronavale markings on one side of the fuselage, retaining RN markings on the other side.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Регистрационный номер: XX153 [2] Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Регистрационный номер: XX510 [2] The second Naval trials Lynx, XX510, carrying four Aerospatiale AS12 air-to-surface missiles
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
To facilitate stowage aboard small ships, the Lynx has folding main rotors and folding tail rotor pylon.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Accessibility of the Rolls-Royce Gem engines is clearly shown here; the engines themselves are of modular construction in seven major components.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
A close-up of the Ferranti Seaspray radar in the nose of a Naval Lynx.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Emergency flotation bags can be carried on the stub wings and are shown here inflated for test purposes.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Регистрационный номер: XX904 The first of two development Lynx airframes in Aeronavale configuration, used by Aerospatiale in France to develop specific French role equipment.
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
-
Westland/Aerospatiale Lynx HAS Mk 2
Самолёты на фотографии: Westland Lynx - Великобритания - 1971
