The XF2F-1 as originally flown in 1933

Самолёты на фотографии: Aircrafts on the photo: Grumman F2F - СШАUSA - 1933

F2F-1 BuNo 9624, the second production example, issued to “Fighting Two” in February 1935 and subsequently serving aboard Lexington. VF-2B was to operate its F2F-1s continuously from Lexington until the end of September 1940

Самолёты на фотографии: Aircrafts on the photo: Grumman F2F - СШАUSA - 1933

The XF2F-1 after introduction of new engine cowling incorporating rocker arm blisters, telescopic gun sight, and radio masts and aerials.

Самолёты на фотографии: Aircrafts on the photo: Grumman F2F - СШАUSA - 1933

F2F-1s and F3F-1s undergoing overhaul at Grumman's Long Island facility with F3F-1 assembly in the background.

Самолёты на фотографии: Aircrafts on the photo: Grumman F2F - СШАUSA - 1933Grumman F3F - СШАUSA - 1935

Самолёты на фотографии: Aircrafts on the photo: Grumman F2F - СШАUSA - 1933Grumman F3F - СШАUSA - 1935

F3F-3 BuNo 1463 photographed at Anacostia on 7 April 1939.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

F3F-2 (BuNo 1003), the 37th production example, prior to delivery to 3rd Section of Fighting Squadron Six aboard Enterprise.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

F3F-1 BuNo 0262 of VF-7 deployed aboard Wasp from late 1939, this being one of nine aircraft relinquished by VF-3.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

К концу 1940 года в процессе принятия на вооружение находились Brewster F2A-1 и Grumman F4F-3 - это был закат эпохи F3F. Впрочем, последние до конца 1941 года использовались в качестве учебных.
F3F-2 BuNo 0995 after withdrawal from first line service and reassignment for fighter pilot training at Corpus Christi and Jacksonville, the last active F3F-2s being stricken from the records of serviceable aircraft during November 1943.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

F3F-2 BuNo 0968 prior to delivery in November 1937 to “Fighting Six” aboard Enterprise

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

F3F-3 BuNo 1445 assigned to VF-5 aboard the Yorktown from May 1939, this being the last carrier-based squadron to convert to monoplanes, flying its F3F-3s until mid-1941.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

F3F-2 BuNo 0994 of VMF-2's 3rd Section, this Marine Corps unit relinquishing (as VMF-111) its F3F-2s in July 1941.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

F3F-1 BuNo 0257 of Marine squadron VF-4M; this unit was redesignated VMF-2 from 1 July 1937 and re-equipped with the F3F-2 in the following year.

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

Grumman F3F-3

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935

The general arrangement drawing below depicts the F3F-3, the upper sideview illustrating the XF3F-3

Самолёты на фотографии: Aircrafts on the photo: Grumman F3F - СШАUSA - 1935
