Фотографии
-
Регистрационный номер: WB338 Firefly AS.5 WB338/239 operated with No 810 Sqn from HMS Theseus in October 1951, making effective ground strikes in Korea.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: VT488 Firefly FR.5 VT488 was operated from HMS Glory by 821 Sqn during the Korean conflict, the type proving itself a formidable ground-attacker.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Fairey Firefly T.1 trainers photographed in 1948. A Royal Navy Firefly formates on the Royal Netherlands Naval Air Service example in the foreground.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: VH142 RCN Firefly AS.6 VH142, on display at the Warplane Heritage Museum in Ontario.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WD826 Firefly AS.6 WD826 is operated by the RAN Historic Flight at Nowra and is still airworthy, but seldom flown.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WB271 After several years of refurbishment and repainting, RN Historic Flight Firefly AS.5 WB271 should be flying again in the near future.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: SE-BRL Swedish TT.1s were yellow overall, often with a red arrowhead motif on their drop tanks and rudder.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
This picture of two Firefly U.9s at Hal Far illustrates the colourful red-and-yellow markings used for high visibility.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The Firefly FR.Is of the Imperial Ethiopian Air Force deteriorated at Asmara in the 1970s. Canadian Navy markings show through on the second aircraft.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: VT425 In late 1947, Fairey moved Firefly production from Heston to Hayes, where this picture of an almost-completed Dutch Navy Firefly FR.4 was taken in April 1948.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WD917 [2] Firefly AS.6 WD917/203 was operated by No 1840 Sqn of the RN Volunteer Reserve at Ford in May 1953, when this picture was taken.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: Z1832 A striking Charles Brown photograph of Firefly Z1832. The elliptical wings made the Firefly more aesthetically pleasing than its Fulmar forerunner.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WD917 [2] Firefly AS.6 WD917 banks gently towards its base at Ford.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: VT395 Firefly AS.5 VT395 prepares to take off using the deck catapult. The launch strops have been fitted to the catapult spools; the strops are then tensioned, the pilot applies full power and, at the signal, the Firefly is launched over the bows.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
To enhance take-off performance under loaded conditions, especially on a flight deck with little wind, a rocket-assisted take-off (RATO) was achieved using rocket motors attached to the sides of the Firefly’s fuselage.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: MB757 The prototype Firefly 7, MB757, with a “guess which mark I am today?” look about it. Note the placing of the radiator under the spinner, similar to the Mk I, the revised wing form with elliptical wingtips, double blown canopy for the observers and Mk IV tailplane.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The Rolls-Royce Griffon 74 was a two-speed, two-stage supercharged engine built to a Royal Navy requirement, specifically for the Firefly IV.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A pair of RAN Firefly target tugs of No 851 Sqn from Nowra drop in at Bankstown Airport near Sydney.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Самолеты Fairey Firefly из 820-й эскадрильи голландской морской авиации стреляют ракетами по позициям индонезийских партизан в горных районах Явы к югу от Сурабаи.
It was not only British or Commonwealth Fireflies that flew operationally. Here three Fireflies of the Dutch Navy attack rebel positions in the hills of the Dutch East Indies.Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WB351 Bombed-up Firefly FR.5 WB351 of 817 Sqn aboard HMAS Sydney prepares to be launched on another strike in South Korea. Note the identification stripes used during the conflict.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A batsman in action during a dummy deck landing at Eglinton in Northern Ireland, where No 816 Sqn was re-formed in 1948 as a Royal Australian Navy unit with 12 Firefly FR.4s. The squadron embarked in HMAS Sydney in February 1949, and after re-equipping with Firefly Mk 5s and 6s in 1951, took part in the Monte Bello Islands atomic bomb tests in October of the following year.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A Firefly FR.4 of No 5 Sqn, Dutch Navy, returns from a strike (note empty rocket rails) to Biak in New Guinea in 1960.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The wide wheel track on the Firefly gave good stability for operations from a carrier deck. This example is one of 40 FR.4s built for the Dutch Navy.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: VT406 The Firefly IV was essentially the same as the previous marks, other than that a 2,245 h.p. Griffon 74 engine was installed, and the coolant and oil radiators shifted to the leading edge.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WJ216 The final Firefly 7 design with a wider-span tailplane and enlarged fin and rudder.
WJ216 was the second of two pre-production Firefly A.S.7s. Note the deletion of the arrester hook in this T.7 version.Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The start of another day’s test flying at White Waltham in 1948. Seven Fireflies await their pilots - from left, Lt D.D. Peacocke, Sqn Ldr J. Mathews, Gordon Slade and Peter Twiss.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: PP402 One of the Firefly FR.Is supplied to the Royal Canadian Navy was PP402, here clearly displaying its ASH pod.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Korean winters were harsh, and strike operations from wet and icy flight decks were frequently made under appalling conditions, like those in this picture of HMAS Sydney in 1951.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Five Firefly Mk Is were converted at Hamble into TT.1s, and delivered to the Indian Navy for target-towing duties in 1954.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: MB750, G-AHYA Firefly FR.I MB750 was adapted to become the prototype T Mk 1 in the summer of 1946, and won the 1947 Lympne High-Speed Handicap race at an average speed of 290 m.p.h.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The U Mk 8 was developed from the Firefly 7 in 1952 for use as a pilotless drone. Note the wingtip camera pods.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: VT485, VT487 This unusual picture shows two Firefly U.9s of 728B Sqn based at Hal Far, Malta, in July 1958. The nearest, VT487/590, is pilotless, while VT485/595 is being flown conventionally.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Resembling a particularly vicious insect from head-on, this Mk I demonstrates its neatly folding wings, which had to be folded manually - a job requiring a sizeable groundcrew.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A Danish Air Force Firefly TT.1 625 on a sortie. Its early ancestry as an F.I is apparent in the low windscreen and flat pilot’s canopy.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: TW695 Peter Twiss taxies Firefly IV TW695, which was fitted with contra-rotating propellers in a bid to negate the swing effects of torque; the idea was never adopted for service.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The pugnacious-looking Firefly IV introduced a number of changes to the airframe, notably the relocation of the coolant and oil radiators from the nose to the leading edge centresection, a revised tail structure and clipped wings. The underwing pods contained radar in the starboard and fuel in the port. Note the unusual underwing roundels “wrapped around” each pod.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The Firefly was capable of carrying an impressive range of armament and equipment under the wings. For ground-attack, the aircraft could be fitted with various combinations of bombs and rocket projectiles (RPs), and mines or depth charges with AN/ARR-3 sonobuoys for the anti-submarine role.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A bombed-up Firefly FR.1 of the Royal Thai Air Force sits ready for a strike on rebel targets.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
According to one pilot, the Firefly cockpit was totally disorganised, although it retained the standard blind-flying panel. This meant scanning the instruments constantly, instead of sweeping left to right as normal.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Fairey T.7 rear cockpit
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Регистрационный номер: WD833 Firefly AS.6 WD833 under restoration in the USA by Gene Fisher in the 1970s. It is still being worked on by its new owners today.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A flak-damaged Firefly FR.1 of 1770 Sqn is rapidly moved forward on HMS Indefatigable to make way for the next aircraft to land on.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
A Firefly FR.4 suffers a broken port undercarriage leg during a deck landing on an unidentified Royal Navy carrier. Because the tailwheel was fully castoring, it was highly directionally unstable, making it easy to write off the undercarriage during the landing run.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
These Firefly relics were photographed in a scrapyard at Failsworth, Lancs. Most were saved to become cockpit exhibits.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Firefly F Mk I
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The Fairey-Youngman flaps fitted to the Firefly were fully retractable, unlike those on the Fairey Barracuda, and gave the Firefly remarkable performance in the turn.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
LEFT Artist J.H. Clark of The Aeroplane drew this sketch in 1945 to illustrate how the Firefly’s fuselage was built in two halves, and then joined along a vertical axis - the first metal aircraft to feature this construction method.
RIGHT A diagram of the outer wing structure of the Firefly, which incorporated a new design of wing-folding joint which gave a positive lock of great strength.Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The Firefly IV was essentially the same as the previous marks, other than that a 2,245 h.p. Griffon 74 engine was installed, and the coolant and oil radiators shifted to the leading edge.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The massive one-piece centre section of the Firefly wing was offered up to a corresponding recess in the fuselage, and provided impressive strength. Note the additional view of the wing-folding hinge pick-up at A.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
The first two stages in the development of the Firefly. The top drawing is the design offered by Chaplin to the revised specification N.9/39, and the bottom the interim design taking in the requirements of the new N.5/40 specification.
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
-
Fairey Firefly FR.4
Самолёты на фотографии: Fairey Firefly - Великобритания - 1941
