Фотографии
-
The 1931 Puss Moth, straight off the production line! This is one of several publicity photos to show the latest version. Apart from its fatter Dunlop 'Intermediate' low-pressure tyres it looks the same as any of the 285 DH.80As built.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
The first prototype, c/n 396, the only DH.80, was an all-wood aircraft built to try out the design as a flying machine and confirm the suitability of its layout. The two right side doors, here seen open, were changed on production to one each side.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
The DH.80 was test flown as E-1 as seen in this flight view. A modification added an oil tank on the port side, for which the side cowl flap has been cut away for clearance.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
A close-up of the Moth III with a door each side also shows the airbrakes provided by rotating the undercarriage main leg fairings through 90°. At the rear of the right side cowling flap is the intake for the Claudel-Hobson downdraught carburetter.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: PH-ATI C/n 2002 was sold to Holland in May 1938 becoming PH-ATI with D H Reinders. It is shown here with the owner and his wife at Rijswijk (a suburb of The Hague) on 23.9.38 as they were about to depart for the tenth annual Meeting of the German Aero Club at Munster. Ironically, the Puss Moth was destroyed in the German advance less than two years later.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: CF-AGO [3] C/n 2004 became CF-AGO, now named Puss Moth and the first in Canada. It is seen at the DH Toronto aerodrome with pilot Geoffrey S O'Brian and officials of DH, Canadian Airways and Prospector Airways
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
This flight view of the Moth III shows the cut-away wing roots, mud scrapers on the wheels, typical DH tail unit and tailskid, the latter most suitable for the grass airfields of pre-war years. This and the previous photograph are thought to show c/n 2001, here being flown with only the G- registration prefix under the wing. Together with the next three photos they were published on 25th April 1930.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Early aircraft had already been allocated to customers, but an example from lower down the production line not showing a registration was selected for publicity. It was identified as the DH.80A Moth III. This head-on view shows the narrow large diameter wheels with high pressure tyres.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: CF-AGO [3] CF-AGO, now modified with a tailwheel and lower pressure tyres, with Mr E Leigh Capreol and on the side the names of the places he visited on a tour of North America.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: G-AAVB [2], SU-AAB [2] G-AAVB c/n 2003 was flown by Col. the Master of Sempill from the Welsh Harp at Hendon on a tour of the Baltic and Scandinavia in September 1930, returning to Scotland. The seaplane version had Short Bros floats which reduced cruising speed by 10-15 mph.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
In this view of the DH.80 prototype the flat plywood covering of the fuselage can be seen, also the large wing dihedral which was deleted on production aircraft.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: G-AAVB [2], SU-AAB [2] G-AAVB reverted to landplane in Egypt in 1931 when owned by Alan Muntz of Airwork. It stayed there as SU-AAB until it was written off on 4.9.41.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: G-AAXJ [2], VT-ACZ [2] A close-up of c/n 2006 G-AAXJ, with owner smiling in the cockpit, shows the oil tank with the cowling closed over the front end like the Tiger Moth.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
The Moth III in flight shows clean lines and the long underside exhaust pipe which kept fumes away from the cockpit and reduced noise.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: G-AAXJ [2], VT-ACZ [2] G-AAXJ c/n 2006 in flight shows no differences from the early Moth III photos. It is being flown by its new owner whose name is given as Buckingham on the back of another photo.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: CF-AGO [3], CF-AGT, CF-IOL Puss Moths at the opening of Vancouver Airport in 1931; CF-AGO (2004) with v.p. prop, CF-IOL (DHC219) and CF-AGT (2018).
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
-
Регистрационный номер: G-AAEF, G-AAXS, G-ABLX, G-ABSH, G-ABXS, G-ACFR, G-ACLZ, G-ACRX, G-ACVJ, VT-ACI, G-ADLP Aircraft being overhauled and resprayed (possibly at Heston in early 1935) include Puss Moth G-AAXS c/n 2009 (centre) after its return from the Middle East, with behind it VT-ACI c/n 2111 about to become G-ADLP. Left is Puss Moth G-ABLX c/n 2173 and clockwise Fox Moth G-ABXS, DH.60G G-AAEF(?), Avro Commodore G-ACRX, Airspeed Envoy G-ACVJ and Monospar ST-4 G-ACFR. Outside are Leopard Moth G-ACLZ and DH.60G G-ABSH.
Самолёты на фотографии: Airspeed Envoy / AS.6 - Великобритания - 1934Avro Commodore / Type 641 - Великобритания - 1934De Havilland Fox Moth / D.H.83 - Великобритания - 1932De Havilland Gipsy Moth / Moth X - Великобритания - 1928De Havilland Leopard Moth / D.H.85 - Великобритания - 1933De Havilland Puss Moth / D.H.80 - Великобритания - 1929General Aircraft Monospar ST-4 - ST-12 - Великобритания - 1932
-
Geoffrey De Havilland in his usual soft felt hat, flying the DH.80 prototype. Not all the instruments are yet fitted, but an altimeter and ignition switches can be seen. The essential ASI, RPM Indicator and Oil Pressure Gauge were on the left of the panel.
Самолёты на фотографии: De Havilland Puss Moth / D.H.80 - Великобритания - 1929
