Air-Britain Aeromilitaria 2003-02 / Specification T.1/37

Регистрационный номерRegistry number: L7714   [2]

Miles M.15 L7714

Мировая Авиация 194

Учебный M.15 с открытыми кабинами обладал неудовлетворительными летными данными.

Air-Britain Aeromilitaria 2003-02 / Specification T.1/37

Регистрационный номерRegistry number: L7714   [2]

Miles M.15 L7714

Air-Britain Aeromilitaria 2003-03 / Miles M.18

Регистрационный номерRegistry number: HM545

The second prototype M.18 as HM545

Мировая Авиация 194

Регистрационный номерRegistry number: JN703   [3], U0236   [3]

Второй экземпляр самолета M.18 доработали в летающую лабораторию для изучения способов увеличения подъемной силы крыла, но потом вернули в оригинальный вид.
The Miles M.18 (JN703) fitted with slotted flaps and leading-edge slats as used on the Supermarine S.24/37.

Air-Britain Aeromilitaria 2003-04 / Picture Pages

Регистрационный номерRegistry number: JN703   [3], U0236   [3]

Following on from the item in the last issue on the Miles M.18, this photo shows U11, the fourth prototype built for trials at the Royal Aircraft Establishment. It had span-wise leading-edge slots and full-span slotted flaps. The tailplane and elevator were increased in size but control was poor at low speeds and the aircraft was laterally unstable. Upturned wingtips were later fitted and in this form it is seen at Woodley. The designation M.18HL was applied and it later became JN703.

Jane's All the World Aircraft 1946 / 03 - All the world's aeroplanes

The Miles M-18 Two-seat Primary Training Monoplane (150 h.p. D.H. Gipsy-Major III engine).

Air Pictorial 1957-01 / Photos by request

Регистрационный номерRegistry number: JN703   [3], U0236   [3]

SLOTTED FLAPPERY. Another unusual Miles Aircraft research project was a High Lift (H.L.) wing for R.A.E., Farnborough. The H.L. wing was fitted to a 1939-designed M.18 - one of four constructed. The M.18H.L. was built up in 1942 and proved to have a lift coefficient of 3. The former R.A.F. serial JN703 was replaced by the company's registration (originally U-0236) latterly U.II.

Aeroplane Monthly 1994-04 / 1994 UK Aircraft Collections and Museums Guide

Регистрационный номерRegistry number: G-AHKY   [3]

Rex Coates in the Miles M.18 G-AHKY, now preserved at the Museum of Flight, East Fortune

Aeroplane Monthly 1996-08 / 1996 UK Aircraft Collections and Museums Guide (2)

Регистрационный номерRegistry number: G-AHKY   [3]

Miles M.18 Mk 2 G-AHKY is preserved at the Museum of Flight at East Fortune.

Air-Britain Archive 1983-04 / U.K. C of A Applications (16)

Регистрационный номерRegistry number: G-AHKY   [3]

Miles M.18 G-AHKY at Coventry on 15.7.61 when it won the Kings Cup Air Race piloted by Brian lies at an incredible 142 mph.

Air-Britain Aeromilitaria 2003-03 / Miles M.18

The third prototype M.18 U-3 with cockpit canopy.

Aeroplane Monthly 1989-03 / Personal album. Civil

Регистрационный номерRegistry number: G-AHOA, U0238

Miles M.18 Mk 3 G-AHOA was built in 1943 and first flown at Woodley as U-3, later becoming U-0238. After the war it was civilianised and purchased in 1948 by Mrs E. M. Porteous, who based it at Burnaston, Derby. After being sold to Tom Hayhow 'OA was lost in a crash at Littondale, Yorks on May 25, 1950. Similar to the Miles M.18 Mk 2, the Mk 3 sported an enclosed cockpit.

Air-Britain Aeromilitaria 2003-03 / Miles M.18

Регистрационный номерRegistry number: U0222

The first prototype M.18, as U-0222, modified with a tricycle undercarriage and four-bladed propeller and converted to a single-seater.

Aeroplane Monthly 2001-04 / Airshows & Museums Guide

A general view in the Museum of Flight at East Lothian, showing a Bulldog, Jetsream, Twin Pioneer, Beech 18 and the tail of the Miles M.18.

Другие самолёты на фотографии: Another planes on the photo: Beagle/Scottish Aviation Bulldog / B.125 - ВеликобританияUnited Kingdom - 1969Beechcraft Model 18 / C-45 Expeditor - СШАUSA - 1937Handley Page/BAe Jetstream / H.P.137 - ВеликобританияUnited Kingdom - 1967Scottish Aviation Twin Pioneer - ВеликобританияUnited Kingdom - 1955
