Мировая Авиация 74

Регистрационный номерRegistry number: G-EAVP   [6]

После установки двигателя Lucifer на самолет М.1С появилась гоночная модификация М.1D Monoplane. Самолет пользовался большим успехом, но разбился во время соревнований "Grosvenor Cup Race" в 1923 году.

Aeroplane Monthly 1978-08 / Bristol M.1C /Preservation Profile/ (64)

Регистрационный номерRegistry number: C5001   [6], VH-UQI   [6]

Aeroplane Monthly 2001-11 / Navigator

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Bristol M.1C “C4918”, seen here being flown by “Dodge” Bailey, has been a popular performer at Shuttleworth shows this season.

Aeroplane Monthly 2000-12 / News

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

A DOUBLE FIRST occurred at Old Warden on September 25, 2000, when Shuttleworth Collection Southern Martlet G-AAYX flew for the first time after a long restoration, and Bristol M.1C reproduction G-BWJM/“C4918", built by Northern Aeroplane Workshops, made its first ever flight.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Shuttleworth Collection chief pilot Andy Sephton flying Bristol M.1C G-BWJM/"C4918” over the aircraft's base at Old Warden Aerodrome in Bedfordshire.

Aeroplane Monthly 1997-06 / M.Oakey - Vintage news

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Northern Aeroplane Workshops handed Bristol M.1C flying replica “C4918” over to Shuttleworth at the new Skopos motor museum at Batley on April 12, 1997. Eyecatchingly painted in the red-brown PC 12 finish of a 72 Sqn aircraft serving in Mesopotamia in 1918, it should be at Old Warden by mid-season.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

"C4918" takes pride of place among the classic cars at the Skopos Motor Museum in Batley in 1997.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

The prototype Bristol M.1A monoplane first appeared in July 1916; note the early hoop-shaped cabane struts. In the middle of the group at right is Sir George White, founder of the Bristol Aeroplane Company.

Air International 1996-03 / R.Whitford - Fundamentals of Fighter Design (2)

The Bristol M.1C Bullet which first flew in 1916 was an aerodynamically clean monoplane and achieved 114kts with only 80kW from its le Rhone rotary engine. However, it succumbed to technical opposition by virtue of the monoplane’s supposed lack of structural integrity. Only 125 were built and relegated to operations in secondary theatres of war.

Flight 1940-02 / Flight

The first monoplane fighter. Note the large spinner over the rotary engine. 1916

Flight 1930-01 / Flight

The little monoplane is a "Bristol," and was flown in several races after the war, winning one of them (Aerial Derby) piloted by the late Larry Carter. The almost totally enclosed rotary engine is an interesting feature.

Aeroplane Monthly 1990-03 / Personal album. Civil

Регистрационный номерRegistry number: G-EAER   [3], C4964   [3]

Seen competing in the 1919 Aerial Derby at Hendon in June 1919 is this partially-converted Bristol M.1C flown by owner Maj Chichester Smith. Formerly C4964, this M.1C was registered G-EAER shortly before the race. Numbered 12 for the Aerial Derby, it developed a problem with its 110 h.p. le Rhone rotary engine and was forced to retire.

Air-Britain Aeromilitaria 1991-04 / Picture pages

Регистрационный номерRegistry number: C4964   [3], G-EAER   [3]

Bristol M. 1C C4964 was shipped to Australia where it became the mount of Captain Harry Butler. Painted red, it carried the name Red Devil and was used to give aerobatic displays. After the death of Butler, it was bought by Horrie Miller who installed a Gipsy I engine and rebuilt the fuselage to be flat-sided. It was refused a C of A in 1936 and in 1958 returned to Butler's home town of Minlaton, SA, where it was placed in a museum to his memory. Now rebuilt to original standards, it carries RAF markings and its original serial and is on display in a special exhibition hall at Minlaton.

Aeroplane Monthly 1998-10 / R.Riding - A Broad experience (1)

Регистрационный номерRegistry number: C5002

Bristol M.1C C5002 of No 2 Flying School, Marske. While on a course at Marske in 1918, Broad flew sister aircraft C5003. He found it simple to handle, but rather difficult to loop.

Jane's All the World Aircraft 1980 / Encyclopedia of Aviation - Aircraft A-Z - v2

Регистрационный номерRegistry number: C5008

Bristol M.1C monoplane.

Air Enthusiast 1997-05 / B.Cumming - Triple DSC

Регистрационный номерRegistry number: C5012

Bristol M.1C Monoplane C5012, possibly attached to the School of Aerial Gunnery and Fighting at Freiston when Joe Fall was stationed there.

Aeroplane Monthly 1991-02 / Personal album. Military

Регистрационный номерRegistry number: A5140

A5140, the second of four Bristol M.1Bs built, at Filton in December 1916. Although allotted to the RFC in France in February 1917, it never went there, joining 111 Sqn in Palestine instead. In the background of this picture is what appears to be a B.E.2d fitted with B.E.2e-style unequal-span wings.

Другие самолёты на фотографии: Another planes on the photo: RAF B.E.2e - ВеликобританияUnited Kingdom - 1916

Aeroplane Monthly 1978-08 / Bristol M.1C /Preservation Profile/ (64)

Регистрационный номерRegistry number: C5001   [6], VH-UQI   [6]

As it is today, repainted and with a Le Rhone rotary refitted

Air Pictorial 1957-11 / Photos by request

Регистрационный номерRegistry number: C4964   [3], VH-UQI   [6], C5001   [6], G-EAER   [3]

MORE BRISTOL M.1Cs. In the July issue of Air Pictorial, J. M. Bruce described the Bristol M.1C and made passing reference to the Gipsy-powered version. Bristol Press Dept.'s Philip Moyes has discovered a photograph of VH-UQI fitted with a hybrid D.H. Gipsy II/III inline. It is believed to be the same airframe (lower) as flown by Major Chichester-Smith in the 1921 Aerial Derby. This M.1C (R.A.F. serial C4964) possessed the non-standard, faired headrest also seen on VH-UQI. The Australian M.1C was purchased in England by Capt. H. Butler, and was used for exhibition flying over several years. After his death the M.1C was stored in a garage roof until purchased by Mr. H. Miller who initially re-engined it with a Gipsy I; winning the 1932 Australian Aerial Derby.

Aeroplane Monthly 2001-11 / Navigator

Регистрационный номерRegistry number: VH-UQI   [6], C5001   [6]

The "Veteran" Bristol monoplane in flight. With a Gipsy engine, being flown by Horrie Miller late in 1931
R.A. White submits a cutting from the September 1933 Popular Flying on H. Miller’s Bristol M.1C Monoplane VH-UQI, which, after fitting a D.H. Gipsy I engine, he entered in the Australian Air Derby for two years, coming first each time but being disqualified on the second for “exceeding the speed estimate”. Mr White wonders what the qualifying speed would have been, and what became of VH-UQI. I can answer the last question - it is preserved at the Captain Harry Butler Memorial at Minlaton, South Australia, in a purpose-built structure opened in 1958 and has been restored with a le Rhone radial engine to its original configuration. Harry Butler had brought two M.1Cs to Australia, one in 1919 and a second later.

Aeroplane Monthly 1978-08 / Bristol M.1C /Preservation Profile/ (64)

Регистрационный номерRegistry number: VH-UQI   [6], C5001   [6]

On display at Minlaton after restoration in 1957

Air Pictorial 1958-01

A Bristol M.1 fighter of World War I painted overall with feathers is another of the strangely-decorated aircraft of the period.

Aeroplane Monthly 1999-06 / P.Jarrett - Creatures of the air /Strange plumage/

Регистрационный номерRegistry number: C5025

Finely fledged Bristol M.1C Scout C5025 was one of several given garish colour schemes by the Royal Flying Corps’ Schools of Aerial Fighting in the UK, where the type was evidently popular with instructors despite its rejection for use by fighter squadrons on the Western Front. This particular machine, the last M.1C to be built, was with No 3 Fighting School at Bircham Newton. The unit’s Chief Fighting Instructor, Maj H. H. Balfour (the late Lord Balfour of Inchrye), who flew the aircraft, recalled that the scheme was applied by Mr Shepperson, an artist with the satirical magazine Punch, whose son was a flight commander with No 3 FS.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C5014   [2]

Bristol M.1C C5014 wore a dazzling crosshatch-and-sunburst colour scheme, typical of the personal aircraft used by RFC flying instructors.

Aeroplane Monthly 1983-03 / ??? - Check mates

Регистрационный номерRegistry number: C4995

Bristol Monoplane C4995, named The Lilac Domino, was probably the personal aircraft of Maj P. Q. Studd, DSO, and it ended its days when written off in a crash near Stonehenge in 1918.

Aeroplane Monthly 1979-08 / ??? - Thorpe park

Регистрационный номерRegistry number: C4912   [3], C4994   [3], G-BLWM   [3]

Replica Bristol M.1C C4912.

Aeroplane Monthly 1978-08 / Bristol M.1C /Preservation Profile/ (64)

Регистрационный номерRegistry number: C5001   [6], VH-UQI   [6]

Butler and Kauper after buying C5001, at Waddon in July 1919

Aeroplane Monthly 1987-08 / M.Oakey - Grapevine

Регистрационный номерRegistry number: C4912   [3], G-BLWM   [3], C4994   [3]

Don Cashmore's beautiful Bristol M.1C replica, G-BLWM, flew for the first time on June 21, 1987. It carries the serial C4912, which originally belonged to an M.1C serving with 150 Sqn at Salonika in 1918.

Aeroplane Monthly 1978-12 / R.Halley - Per Ardua ad India

Preparing for departure. The popular practice of putting the smallest available machine next to the biggest has been adopted, with a Bristol M.1C monoplane playing the part of “David” in this instance.

Другие самолёты на фотографии: Another planes on the photo: Handley Page H.P.15 (V/1500) - ВеликобританияUnited Kingdom - 1918

Air-Britain Aeromilitaria 1993-02 / Handley Page O/400

Регистрационный номерRegistry number: C5014   [2]

C3498 visiting No. 32 TDS, Montrose, with a gaily-painted Bristol M.1C C5014 for scale

Другие самолёты на фотографии: Another planes on the photo: Handley Page H.P.12 (O/400) - ВеликобританияUnited Kingdom - 1917

Flight 1922-04 / Flight

The Bristol "Lucifer" 100 h.p. engine, mounted in the very pretty little Bristol monoplane flown by Mr. Uwins. Considering that this engine has three cylinders only, it runs very smoothly and evenly.

Flight 1923-06 / Flight

The Grosvenor Cup. In Birmingham Control. The late Major Foot, M.C., indulging in a cigarette just before leaving. This is probably one of the last photographs ever taken of this greatly-loved pilot

Flight 1922-08 / Flight

Регистрационный номерRegistry number: G-EAVP   [6]

THE AERIAL DERBY: The Bristol Monoplane, 100 h.p. Bristol "Lucifer."

Flight 1922-09 / Flight

Регистрационный номерRegistry number: G-EAVP   [6]

Bristol Monoplane, 100 h.p. Bristol "Lucifer."

Flight 1930-01 / Flight

Typical Aerial Derby machine: Bristol "Bullet" (400 h.p. Bristol "Jupiter").

Flight 1922-04 / Flight

Регистрационный номерRegistry number: G-EAVP   [6]

AT THE CROYDON MEETING ON EASTER MONDAY: Uwins getting off on the Bristol monoplane, with 100 h.p. Bristol "Lucifer" engine.

Flight 1922-06 / Flight

Регистрационный номерRegistry number: G-EAVP   [6]

AIR RACING AT WADDON: Uwins, on the Bristol monoplane, 100 h.p. Bristol "Lucifer" engine, winning the First Whitsuntide Handicap.

Flight 1939-03 / Flight

Регистрационный номерRegistry number: G-EAVP   [6]

PROM THE AERIAL DERBY: L. L. Carter crosses the finishing line as first man home and winner of the Derby Handicap.
A Bristol monoplane with Lucifer engine was a low-power version of the military monoplane.

Flight 1923-06 / Flight

THE GROSVENOR CHALLENGE CUP: Preparing some of the machines before the start at Lympne. From left to right may be seen the Sopwith "Gnu" (Longton), the Bristol monoplane (Foot), and a 504K Avro (Hamersley).

Другие самолёты на фотографии: Another planes on the photo: Avro Avro 504 - ВеликобританияUnited Kingdom - 1913Sopwith Gnu - ВеликобританияUnited Kingdom - 1919

Flight 1920-04 / Flight

The Bristol "family" at Home. Left to right: The Bristol Babe, the Bristol monoplane, the Bristol Badger, the Bristol Fighter, the Bristol Tourer and the Bristol Pullman triplane

Другие самолёты на фотографии: Another planes on the photo: Bristol Babe - ВеликобританияUnited Kingdom - 1919Bristol Braemar / Pullman - ВеликобританияUnited Kingdom - 1918Bristol F.2A/F.2B Fighter - ВеликобританияUnited Kingdom - 1916Bristol F.2C / Badger - ВеликобританияUnited Kingdom - 1919Bristol Tourer - ВеликобританияUnited Kingdom - 1919

Flight 1939-03 / Flight

The Bristol “family” of 1920. From left to right the types are the Tourer, the Scout type F, the Babe, the monoplane, and the “Brisfit.” Behind them all is the huge Pullman passenger-carrier.

Другие самолёты на фотографии: Another planes on the photo: Bristol Babe - ВеликобританияUnited Kingdom - 1919Bristol Braemar / Pullman - ВеликобританияUnited Kingdom - 1918Bristol F.2A/F.2B Fighter - ВеликобританияUnited Kingdom - 1916Bristol Scout E / F - ВеликобританияUnited Kingdom - 1918Bristol Tourer - ВеликобританияUnited Kingdom - 1919

Aeroplane Monthly 1989-11 / M.Oakey - Grapevine

Регистрационный номерRegistry number: C4994   [3], G-BLWM   [3], C4912   [3]

At Cardington, work on the RAF Museum's Bristol M.1C replica is nearing completion, and the fuselage has been repainted by John Wadham with the dramatic red dragon insignia of RFC training school aircraft C4994 circa 1917-18. Originally built by Don Cashmore and flown briefly as "C4912"/G-BLWM 2yr ago, the replica has had its Warner Scarab engine replaced by a 110 h.p. le Rhone rotary from museum stock, and should be on display at Hendon in time for Christmas.

Aeroplane Monthly 1990-05 / M.Oakey - Grapevine

The uncovered frame of the airworthy member of the trio, a Bristol M.1C which commemorates the first aerial crossing of the Andes, in 1918. Fitted with a Warner Scarab radial (seen here) for flying, the aircraft will later be fitted with a replica le Rhone rotary for static display. A Chilean TV company is interested in re-enacting part of the Andes flight for a documentary.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

ABOVE LEFT Both wings assembled and the fuselage under way on the table at left, at Mirfield in 1991.
ABOVE RIGHT The fuselage, with wicker pilot's seat in place, in September 1992.
BELOW The fuselage with pyramidal cabane struts installed over the cockpit and tailplane (yet to be covered) and fin added.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Trevor Foreman in the "office", with Bob Richardson at far right. The polythene tent was heated to a suitable temperature for doping.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Glowing woodwork and gleaming metal: the high standard of workmanship in this project is evident.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The partly-covered fuselage - note the firewall and the gravity fuel tank (black) in front of the cabane pylon.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Wings covered and fitted, and rigged with lift- and landing wires.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

March 1996, and two of the four fabric segments have now been applied to the fuselage, which resides in the heated "doping tent".

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The cockpit area, with the instrument panel awaiting final installation. The front of the main fuel tank may be seen at lower right behind the seat.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The tail area in March 1996, with rigging and control wires in place, and fuselage side fabric still to be applied.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Alec Hodgins and Stan Summerscales get to grips with bracing wires and the instrument panel in 1993.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Stan Summerscales of the Northern Aeroplane Workshops at work, building the Bristol M.1C

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The late Eric Barraclough, the project's linchpin, covering the port wing in October 1993.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

It is summer 1996; the fuselage is covered and doped, and Eric Barraclough is painting the RFC roundels.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Albert Sugden shapes some timber for the project in January 1993.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The wheels, made by the Motor Wheel Services & Repair Co of London, had motorbike tyres from which the tread was ground off.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Finishing touch: "Palmer Cord Aero Tyre" is added from a stencil.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The 110 h.p. le Rhone rotary engine installation; Shuttleworth supplied the powerplant for the project.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

The fuselage, with engine and cowling in place, nears completion in summer 1996.

Aeroplane Monthly 2002-02 / I.Frimston - Made in Yorkshire /In the workshop/

Регистрационный номерRegistry number: C4918   [23], G-BWJM   [23]

Moving on: the aircraft leaves the NAW workshop at Mirfield for static display at the Skopos Motor Museum in nearby Batley, before going south to its permanent flying base at Old Warden.
