Фотографии
-
The Liberator: Cantilever high-wing of high aspect-ratio. Four radial engines. Deep, slab-sided fuselage, transparent nose; retractable tricycle undercarriage. Rectangular tailplane, oval twin fins and rudders outrigged.
The Condor: Tapered low-wing. Four radial engines. Long shallow fuselage; retractable undercarriage and tailwheel. Tailplane of deep chord with tapered leading-edge. Large fin and rudder of low aspect-ratio.Самолёты на фотографии: Consolidated B-24 Liberator - США - 1939Focke-Wulf FW.200 Condor - Германия - 1937
-
Самолёты на фотографии: Consolidated B-24 Liberator - США - 1939Focke-Wulf FW.200 Condor - Германия - 1937
-
ON ACTIVE SERVICE: Short-nosed Blenheims have been used extensively both for bombing and reconnaissance to help the Greek army in Albania.
Самолёты на фотографии: Bristol Blenheim - Великобритания - 1936
-
Brewster Buffalo. Mid-wing, moderate dihedral from roots, slight taper on both edges, rounded tips. Radial engine. Short, tubby fuselage with enclosed cockpit amidships; wheels retract inwards into underside of fuselage. Elliptical tailplane; straight sloping leading-edge to fin and rounded trailing edge to rudder.
Fiat G 50. Low-wing; anhedral to upper surface only of centre-section (giving very thick roots) which also tapers sharply on both edges, outer panels have moderate dihedral and taper on trailing edges to rounded tips. Radial engine. Hump-backed fuselage, Undercarriage retracts inwards. Elliptical tailplane.Самолёты на фотографии: Brewster F2A Buffalo / B-239 - США - 1937FIAT G.50 Freccia - Италия - 1937
-
Самолёты на фотографии: Brewster F2A Buffalo / B-239 - США - 1937FIAT G.50 Freccia - Италия - 1937
-
"BLOODED": The Grumman Martlet I, now in service with the Fleet Air Arm as a single-seater fighter, scored its first victory - a Junkers Ju 88 - recently.
Самолёты на фотографии: Grumman F4F Wildcat - США - 1937
-
UNITED STATES PLAN: From this picture it is clear that the Mohawk used for the mock fight still had the French armament. The flush-fitting bomb racks under each wing can also be seen.
Самолёты на фотографии: Curtiss Hawk 75 / P-36 / Mohawk - США - 1935
-
BATTLE BEGINS: The Me gets on the Mohawk's tail before starting the inevitable circling match. If the performance of the two machines is equal, it is the one that flies straight to break off the fight which is in danger.
Самолёты на фотографии: Curtiss Hawk 75 / P-36 / Mohawk - США - 1935Messerschmitt Bf.110 - Германия - 1936
-
AMERICA PREPARES: Running up the Twin Wasp engine of the Curtiss Mohawk.
Самолёты на фотографии: Curtiss Hawk 75 / P-36 / Mohawk - США - 1935
-
CZECH-MATES: Ground staff of an all-Czech fighter-squadron refuelling one of their Hurricanes, somewhere in England. On patrol with their British comrades, the Czech pilots have given a very good account of themselves against the Luftwaffe.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
WELL ARMED. Among the aircraft types in the Yugoslav Air Force are Blenheims and Hurricanes. The markings are as shown in this Flight photograph of one of the Yugoslav Hurricanes.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
A Hurricane running up in a floodlight
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
STUKA STINGER: The eight-gun Hurricane I bore nearly the whole brunt of the fighting in France. Despite its hitting power and the fortitude of the pilots, the defection of the French left no alternative but retirement across the Channel.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
GOOD SHOOTING: Sqn. Ldr. R. R. Stanford-Tuck, D.S.O., D.F.C. and Bar has now been awarded a second Bar to the D.F.C. The miniature swastikas indicate his victories.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
SOCIAL CALL. Here is the Duke of Kent having an informal chat with two R.A.F. mechanics. His Royal Highness visited two famous fighter squadrons recently, one a Polish and the other a City of London squadron, when this picture was taken.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
Thousands of men from all walks of life are being instructed as mechanics, fitters and riggers in the R.A.F. training schools, and it is ultimately upon their skill and efficiency in aircraft maintenance that the supremacy of the British fighter-pilot and bomber crew depends. This picture was taken at a typical training school in the West Country where men who were, a few weeks ago, behind office desk or shop counter are now proving keen to learn their new job. Here is a class of flight riggers whose instructor apparently finds a Spitfire cockpit a convenient vantage point from which to lecture.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
This Berliner stretch-press is used for forming curved sheet metal parts very quickly by pressing a steel-covered wood die upward into the curve of the sheet held by its two ends. Note the blast wall of brick built round the machine
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
The fitting of this De Havilland constant-speed airscrew is one of the last operations in final assembly.
A Spitfire has its three-bladed de Havilland constant-speed propeller fitted in 1940/41. Despite the Spitfire's complex shape, considered difficult to produce, the author comments that "at Woolston it seemed no more complicated than the flying-boats which preceded it".Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
"Come and get them." Spitfires lined up on the tarmac waiting to be ferried away by Air Transport Auxiliary. (Inset) Off to a fighter squadron.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
The factory test pilot, just before taking a Spitfire up to show what can be done with it.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
The stern section, complete with fin, is built in paired jigs. Air lines for hand tools come down from overhead reels on which they are wound.
A good illustration of the Spitfire's complex, compound curves: Spitfire rear fuselage/fin assemblies under construction in paired jigs. Note the compressed-air lines for hand tools, descending from overhead reels.Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
Girls cover the petrol tanks with layers of self-sealing rubber and an outer layer of canvas so that bullets can hole the tank without loss of fuel.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
The long chain conveyor, carrying details to be painted, passes through one of the spray booths in which the details receive their first coat on one side.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
FRIEND AND FOE. A Messerschmitt Me 110 captured by the Royal Air Force and now on test under British markings.
Самолёты на фотографии: Messerschmitt Bf.110 - Германия - 1936
-
STRIKING FORCE STRIKERS: Ten Squadrons of the A.A.S.F. in France flew Fairey Battle medium bombers. Two V.C.s were won by No.12 Squadron.
Самолёты на фотографии: Fairey Battle - Великобритания - 1936
-
Vickers Wellington. Mid-wing, wide span, pronounced taper on both edges, small rounded tips, dihedral from roots. Radial or in-line engines. Gun-turrets in nose and tail, lattice-work cabin windows. Tailplane tapers on leading-edge, inverted "V" fin and rudder of high aspect-ratio.
Fiat Br 20. Mid-wing. Anhedral to upper-surface only of centre-section, normal dihedral outboard of radial engines, pronounced taper on trailing-edge, rounded tips. Gun-turrets in nose, amidships (retractable) and in belly. Tailplane tapers sharply on leading-edge only; twin strut-braced fins and rudders.Самолёты на фотографии: FIAT BR.20 Cicogna - Италия - 1936Vickers Wellington / Type 271 - Великобритания - 1936
-
Самолёты на фотографии: FIAT BR.20 Cicogna - Италия - 1936Vickers Wellington / Type 271 - Великобритания - 1936
-
PHOTOGRAPHER PHOTOGRAPHED: During the sitzkrieg, Blenheims of the Air Component were used extensively for photography in addition to other forms of reconnaissance.
Самолёты на фотографии: Bristol Blenheim IV / Bolingbroke - Великобритания - 1937
-
GIVE HIM THE WORKS: A fitter trainee learning the intricacies of the power operated rear gun turret of a Bristol Blenheim.
Самолёты на фотографии: Bristol Blenheim IV / Bolingbroke - Великобритания - 1937
-
A BLISTER FOR A POULTICE: The Consolidated Catalina flying boats have twin Vickers K guns mounted in the midship blister turrets.
The starboard cupola on the rear fuselage of "Cat". Twin Browning machine guns were carried on each side of the fuselage to protect the tail.Самолёты на фотографии: Consolidated PBY Catalina / ГСТ / МП-7 - США - 1935
-
Регистрационный номер: L4710 HOOKED: A Westland Lysander of the Middle East Command picking up a message in the Western Desert.
Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
MAIDS OF ALL WORK: Westland Lysanders, which can be used for message picking up, bombing, reconnaissance, or even fighting at a pinch, were the flying equipment of Nos. 2, 26, 4 and 13 Squadrons.
The Lysanders dive down to deal with some enemy position on the ground.Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
CANADIAN TRAINING R.C.A.F. pilots and Army personnel take part in exercises. The realism of the Army steel helmets is somewhat spoiled by the armchair radio ground station on the right.
Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
TO DROP ON OWN TROOPS: Supply-dropping by parachute containers to forward or isolated troops is one of the important functions of the Westland Lysander.
Fixing supply containers to the bomb carriers of a Lysander.Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
PHOTOGRAPHIC RECCO: The easily removed side panels of the Lysander make the installation of cameras and such-like very simple.
Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
FIGHTER TRAINER: The four-gun Gladiator which has done such excellent work on all fronts is finishing its time as a training type.
Самолёты на фотографии: Gloster Gladiator - Великобритания - 1934
-
AUXILIARY FIGHTERS: The two A.A.F. fighter squadrons with the Air Component - County of Surrey and County of Durham - were equipped with four-gun Gloster Gladiators.
Самолёты на фотографии: Gloster Gladiator - Великобритания - 1934
-
WHERE DO WE GO FROM HERE? "Poor old Benito" may not know the answer, as the popular song suggests, but this Wellington navigator in a Middle-East Bomber Squadron can be relied upon to find his way over the desert or sea - and there's no flying by Bradshaw in those parts!
Самолёты на фотографии: Vickers Wellington / Type 271 - Великобритания - 1936
-
FOR STERN PURPOSES: The rear gunner in a power-operated Nash and Thompson turret of a Middle East Wellington. The reflector sight can be seen in the centre panel.
Самолёты на фотографии: Vickers Wellington / Type 271 - Великобритания - 1936
-
Bristol Bombay. Cantilever high-wing; dihedral outboard of radial-engine nacelles. Gun-turrets in nose and tail and auxiliary gun-position amidships. Fixed undercarriage. Almost rectangular tailplane which bisects twin fins and rudders set well inboard. Horizontal and vertical tail surfaces strut-braced.
Junkers Ju 86K. Low-wing, dihedral from roots, sharp taper; double-wing flaps in three sections. Radial or in-line engines. Gun-turret in nose, retracting "dust-bin" beneath fuselage, open gun position above. Retractable undercarriage. Rectangular, strut-braced tailplane; outrigged twin fins and rudders.Самолёты на фотографии: Bristol Bombay / Type 130 - Великобритания - 1935Junkers Ju.86 - Германия - 1934
-
Самолёты на фотографии: Bristol Bombay / Type 130 - Великобритания - 1935Junkers Ju.86 - Германия - 1934
-
In the flying view the excellent proportions of the boat are emphasised.
Самолёты на фотографии: Saunders-Roe Lerwick / S.36 - Великобритания - 1938
-
The taxying photograph brings out the disposition of the gun turrets and pilot's cockpit.
Самолёты на фотографии: Saunders-Roe Lerwick / S.36 - Великобритания - 1938
-
The interior photograph shows the sending of an emergency message by carrier pigeon - a number of these birds are always carried in case of trouble
Самолёты на фотографии: Saunders-Roe Lerwick / S.36 - Великобритания - 1938
-
The flare rack
Самолёты на фотографии: Saunders-Roe Lerwick / S.36 - Великобритания - 1938
-
A
n aircraftman in the galley.Самолёты на фотографии: Saunders-Roe Lerwick / S.36 - Великобритания - 1938
-
A Blackburn Skua under engine tent and cockpit cover at its dispersal point. Rugger fans may recognise the figure as a referee of happier days. He is now Lt. Allport of the R.N.V.R.
Самолёты на фотографии: Blackburn Skua / B-24 - Великобритания - 1937
-
APART from its beauty of outline, the Merlin-engined Fulmar has excellent manoeuvrability and heavy punishing power. Batteries of four machine guns are carried in each wing, outside the disc of the airscrew and, therefore, able to develop their full rate of fire. Beneath the fuselage can be seen the spools for catapult take-off. The tail of the photographic machine which appears in one of the pictures belongs to a Fairey Swordfish. The two types in collaboration have done excellent work in the Mediterranean. It is likely that the work of the Swordfish in Taranto Harbour more than paid for the whole Swordfish contract.
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937Fairey Swordfish - Великобритания - 1934
-
MODERN BIPLANES: Overhauling Fairey Albacores at a Fleet Air Arm station.
Самолёты на фотографии: Fairey Albacore - Великобритания - 1938
-
WITH HOOK AND SINKER: An intimate shot of a Fairey Albacore with torpedo fitted. The deck landing hook is retracted into the fuselage.
A Fairey Albacore carrying an 18in 1,610lb torpedo. On November 17, 1942, Sub-Lt James Bridge, flying a similarly-armed 820 Sqn Albacore, sank the German submarine U-331.Самолёты на фотографии: Fairey Albacore - Великобритания - 1938
-
BATTLE OF MATAPAN: An impression by "J.P." of Fairey Albacores of the Fleet Air Arm making torpedo attacks on the Italian Fleet in order to slow up their retreat and bring them to action.
Самолёты на фотографии: Fairey Albacore - Великобритания - 1938
-
THE WAVY NAVY: An R.N.V.R. pilot getting aboard a Fairey Fulmar.
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
THE SPIRIT OF THE NAVY: Refuelling a Fairey Fulmar from a mobile tanker.
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
Регистрационный номер: N4070 ALL SET : An instructor perpares to depart on a Fulmar. The four gun ports on the port wing are very apparent.
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
LAND CARRIER: Practising deck landing with a Fulmar on an aerodrome runway. The signal being given denotes the approach was right but do not bother to land, go round again.
Самолёты на фотографии: Fairey Fulmar / P.4/34 - Великобритания - 1937
-
COMMUNICATIVE BIRDS: A brace of graceful Flamingos which were caught on the wing by a Flight photographer.
Самолёты на фотографии: De Havilland Flamingo / D.H.95 - Великобритания - 1938
-
MAESTRO MAINTENANCE: General titivation and refuelling of a Fleet Air Arm Miles Master.
Самолёты на фотографии: Miles Kestrel M.9 / Master I M.9A - Великобритания - 1937
-
MASTERING THE MASTER: With flaps and wheels down a pupil brings in a Miles Master.
Самолёты на фотографии: Miles Kestrel M.9 / Master I M.9A - Великобритания - 1937
-
WINGED CLIPPER. The first of the six new-type Boeing Clippers (which we showed as a "clipped Clipper" moving wingless out of the factory in the March 13th issue) has now been launched and is here seen being taken sideways down the Duwamish River from Seattle to Puget Sound for flight testing. Pan American announce that they expect to increase their present three return Atlantic trips per week to four in May, when the first new boat goes into service. Later, six trips per week will be run. Three of the six new Clippers will be made available to Britain.
Самолёты на фотографии: Boeing Boeing 314 Clipper - США - 1938
-
The Ryan YO-51 was designed for army co-operation and artillery observation. Reminiscent of the Handley Page Gugnunc, the Ryan achieves its low stalling speed by the fitting of full-span slots and Fowler flaps of very wide chord. The performance of this aeroplane has not yet been released by the U.S. Army Air Corps, nor have the details of its lateral control device. Span is 52ft., chord 7ft. 8in., length 34ft. 5in., and the engine is a Pratt and Whitney Wasp of 420 h.p. driving a Hamilton variable-pitch airscrew. The total loaded weight is 3,900 lb.
Самолёты на фотографии: Ryan O-51 Dragonfly - США - 1940
