Фотографии
-
The dihedral of the Whitley commences at the wing joint outboard of the engines. Inboard of this the wing has a horizontal top surface. The projection on the nose is the bomb-aimer's panel of flat glass.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
The wing spar is a huge box of corrugated Alclad and it is made in one piece, complete with engine mountings. After being transported from its jig by an overhead crane, it is placed on this vertical turntable which allows it to be handled easily for painting and other workshop processes.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
Looking forward into the front fuselage during installation. The two upper pin joints by which the front fuselage is attached to the wing spar can be seen; the two lower are concealed.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
A row of Rolls-Royce Merlins mounted and awaiting attachment to thi airframe.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
Fuselages are built on steel jigs by mounting the transverse frames on the jig and then attaching the longitudinal stringers; skin riveting follows.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
DRY DRILL: Dinghy practice from a Whitley fuselage at an O.T.U.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
Applying fabric to 'he rear section ot the wing.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
The undercarriage retracts backward into the engine nacelle.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
The corrugated sheet for the wing spar is supported in the jaws of the riveting machine from an overhead track.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
Front fuselages being fitted with hydraulic, electric and control gear.
Самолёты на фотографии: Armstrong Whitworth Whitley / A.W.38 - Великобритания - 1936
-
THE CONSOLIDATED B-24. also known by the firm's designation of Model 32, in flight over sunny California. Observe how difficult it can be to see a low-flying bomber from the air.
Самолёты на фотографии: Consolidated B-24 Liberator - США - 1939
-
Hawker Hurricane, Single-seater Fighter. Wheels retract inwards, exhaust stubs above centre line. Radiator-scoop, beneath fuselage, in line with cockpit. Rounded wing-tips and fillets at the wing roots. Unbraced tail-plane. Large fin and rudder.
Messerschmitt ME 109, Single-seater Fighter Wheels retract outwards. Exhaust below centre-line. Radiator beneath engine. Square-cut wing-tips, no fillets. Braced tail, small fin and rudder. Two small scoops, one behind each wheel in wing centre-section.Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935Messerschmitt Bf.109E - Германия - 1938
-
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935Messerschmitt Bf.109E - Германия - 1938
-
Typical American control layout
Самолёты на фотографии: Curtiss-Wright C-46 / CW-20 Commando - США - 1940
-
U.S. SHIPBOARD FIGHTER: The Vought-Sikorsky XF4U-1. A single-seater all-metal machine with an 18-cylinder Pratt & Whitney two-row radial of 1,850 h.p.
Самолёты на фотографии: Vought F4U Corsair - США - 1940
-
Supermarine Spitfire, Single-seater Fighter. Wheels retract outwards. Exhaust stubs below centre-line. Radiator beneath starboard wing, oil-cooler beneath port wing. Elliptical wings of deep cord set well forward and with fillets at the roots.
Heinkel HE 113, Single-seater Fighter. Wheels retract inwards. Exhaust below centre-line. Radiator beneath cockpit. Inverted gull wings, angular and tapering in plan. No fillets. Angular fin and rudder of fairly high aspect-ratio.Самолёты на фотографии: Heinkel He-100 - Германия - 1938Supermarine Spitfire - Великобритания - 1936
-
Самолёты на фотографии: Heinkel He-100 - Германия - 1938Supermarine Spitfire - Великобритания - 1936
-
BATTERY AND ASSAULT: The starter battery ready plugged into a Hampden to start up for a raid.
Самолёты на фотографии: Handley Page Hampden / H.P.52 - Великобритания - 1936
-
Westland Lysander: Two-seater. Strut-braced high-wing. Fixed undercarriage with stub-wings for bombs or supply-containers. Squat fuselage with totally-enclosed cockpit. Radial engine. Tail surfaces of large area.
Henschel Hs 126: Two-seater. Strut-braced, parasol wing, back-swept. Fixed undercarriage. Semi-enclosed cockpit. Radial engine. Double strut-braced tailplane set high on fin.Самолёты на фотографии: Henschel Hs 126 - Германия - 1936Westland Lysander - Великобритания - 1936
-
Самолёты на фотографии: Henschel Hs 126 - Германия - 1936Westland Lysander - Великобритания - 1936
-
NOT SO DUSTY: Hurricanes raising a sand-storm as they take off in formation on the Western Desert. These eight-gun fighters have proved themselves as useful on the desert as they were in Europe.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
SIX COUNTIES' PROTECTION: Hurricanes in echelon over Northern Ireland. The slightly differing noses show that both De Havilland and Rotol airscrews are fitted.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
NO BYES ALLOWED: Pilots of No. 601 County of London Squadron, A.A.F., indulge in a game of cricket on the tarmac.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
FOR THE NEXT DOG-FIGHT: Wing gun batteries are attended to simultaneously to save time.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
'Харрикейны" 601-й эскадрильи заправляются и снаряжаются
SPIRITED GATHERING: A trio of Hurricanes refill their tanks with leaded fuel.
Hurricanes of 601 Sqn have their fuel tanks topped up from a bowser while armourers replenish the magazines of the Browning machine-guns.Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
OFF AGAIN: All the care, training and enthusiasm is devoted to one end - well-tuned aircraft ready at any instant.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
FOR HIGH FLYERS: Changing the oxygen bottles on a Hurricane.
Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
A LITTLE TINKERING: Engine fitters giving a Merlin a modicum of titivation. Note the fabric covering
over the gun ports.Самолёты на фотографии: Hawker Hurricane - Великобритания - 1935
-
Bristol Beaufort, Twin-engined Bomber. Wheels retract into nacelles behind small-diameter engines. Deep forward part of fuselage ends amidships in gun-turret. Oil-coolers in leading-edges. Inset wing-tip lights. Single fin and rudder.
Junkers Ju 88, Twin-engined Dive-bomber. Wheels retract into nacelles. Circular nose radiators projecting well forward. Dive brakes below each wing. Faceted nose. Forwardly placed under-turret. Wings taper outboard of engines. Single fin and rudder.Самолёты на фотографии: Bristol Beaufort - Великобритания - 1938Junkers Ju.88 - Германия - 1936
-
Самолёты на фотографии: Bristol Beaufort - Великобритания - 1938Junkers Ju.88 - Германия - 1936
-
WINDY CORNER: An open machinegun port for broadside protection on an Italian bomber.
Самолёты на фотографии: Savoia-Marchetti / SIAI SM.79 Sparviero - Италия - 1934
-
ON THE QUI VIVE: The businesslike and beautiful lines of the Spitfire are accentuated in this side view of a take off. The projection above the windscreen is a mirror to enable the pilot to see if all is clear behind.
Самолёты на фотографии: Supermarine Spitfire - Великобритания - 1936
-
CONVERSATION PIECE: R.F.C. and Army officers in front of a Maurice Farman Shorthorn (note the drooping ailerons). The three officers on the right of the picture are Col. T. O'Brien Hubbard, Gen. Brancker Gen. Sykes.
Самолёты на фотографии: Maurice Farman MF.11 Shorthorn - Франция - 1913
-
ANGLO-FRENCH: An 80 h.p. Bleriot of the type which No.3 Squadron took to France in 1914.
Самолёты на фотографии: Bleriot Bleriot-XI - Франция - 1909
-
Horatio Barber's "Valkyrie" was a tail-first monoplane, with a 50 h.p Green water-cooled engine driving a pusher airscrew.
Самолёты на фотографии: ASL Valkyrie - Великобритания - 1910
-
PRE-R.A.F. LINE UP: Henry Farmans (nearest camera), a Maurice Farman Longhorn and two B.E.s. of the R.F.C. on the tarmac in 1914.
Самолёты на фотографии: Farman HF.15 / 16 / 20 / 22 - Франция - 1912Maurice Farman MF.7 Longhorn - Франция - 1912RAF B.E.2 - Великобритания - 1912
-
Регистрационный номер: 347 D.H. DESIGNED: The B.E.2 had a 70 h.p. Renault engine and lateral control was effected by warping the wings. The covered wheels were an innovation at that time.
Самолёты на фотографии: RAF B.E.2 - Великобритания - 1912
-
Регистрационный номер: 8416 B.E. DEVELOPMENT: Balanced ailerons were used on the B.E.2.C. and a small fin had been added. The engine was a 90 h.p. R.A.F. and the top speed was 72 m.p.h.
This machine was designed by the Royal Aircraft Establishment. The B.E.2C was an automatically stable tractor biplane with 90 h.p. R.A.F. engine.Самолёты на фотографии: RAF B.E.2c/B.E.2d - Великобритания - 1914
-
В боевых условиях Defiant Mk I (на снимке) оказались очень уязвимыми. Но в качестве ночных истребителей зимой 1940-1941 годов им удалось сбить больше вражеских машин, чем любым другим английским ночным перехватчикам.
A NIGHT FIGHTER BY DAY. Between them the two occupants of the Boulton Paul Defiant can survey the entire upper hemisphere and most of the lower.Самолёты на фотографии: Boulton Paul Defiant / P.82 - Великобритания - 1937
-
BROOKLANDS, 1910: A typical aerodrome scene at the period of which Major Turner writes. The machines are a Lane monoplane, Avro triplane and a Voisin.
Самолёты на фотографии: Avro Triplane I - III - Великобритания - 1909Lane monoplane - Великобритания - 1910Voisin Voisin-Delagrange / Voisin-Farman - Франция - 1907
-
EARLY WORK: Army limbers towing a Cody biplane on Laffans Plain.
Самолёты на фотографии: Cody The British Army Aeroplane I - Великобритания - 1908
-
"BIG ACK": Armstrong-Whitworth's second design to go into production, the F.K.8 (160 h.p. Beardmore), was known as the Big Ack.
Самолёты на фотографии: Armstrong Whitworth F.K.8 - Великобритания - 1916
-
ON PARADE: No.16 (A.C.) Squadron with their Westland Lysanders shortly before the war.
Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
UP-TO-DATE: The mobile wireless equipment of a modern A.C. Squadron.
Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
FOR RE-ARMING: Filling a parachute container with small-arms ammunition. The soft aluminium nose of the container is designed to absorb the landing shock.
Самолёты на фотографии: Westland Lysander - Великобритания - 1936
-
UPAVON 1914: In the foreground are two Maurice Farman Longhorns (70 h.p. Renault) with a Henry Farman overhead. The Longhorn had a maximum speed of 50 m.p.h.
Самолёты на фотографии: Farman HF.15 / 16 / 20 / 22 - Франция - 1912Maurice Farman MF.7 Longhorn - Франция - 1912
-
IN HARNESS: Trainees in their flying kit about to start on the day's air work.
Самолёты на фотографии: Airspeed Oxford / AS.10 - Великобритания - 1937
-
QUARTET FOR TWINS: Four pupils off to their allocated Airspeed Oxfords.
Самолёты на фотографии: Airspeed Oxford / AS.10 - Великобритания - 1937
-
"At the instant the motor stops you must descend in vol plane ... with the elevator about level with your feet."
Самолёты на фотографии: Bristol Boxkite - Великобритания - 1910
-
THE BRISTOL BOX KITE. The engine was a 50 h.p. 7-cyl. Gnome rotary. In this machine the occupants were unprotected. A more "refined" version had a little nacelle around the pilot's feet.
Самолёты на фотографии: Bristol Boxkite - Великобритания - 1910
-
OUT FOR SCALPS: The Curtiss Tomahawk which Lord Beaverbrook, in a recent broadcast, described as a good, reliable, straightforward job.
Самолёты на фотографии: Curtiss P-40 Tomahawk - США - 1939
-
TWELFTH EDITION: The B.E.12 had a 150 h.p. R.A.F. engine installed. Its speed was round about 100 m.p.h.
Самолёты на фотографии: RAF B.E.12 - Великобритания - 1916
-
AN AMERICAN HIGH-ALTITUDE FIGHTER. This Republican Lancer, fitted with 1,100 h.p. Pratt and Whitney Twin-Wasp engine, has been designed for work at considerable heights. The engine has a special supercharger, but the operational height of the machine is not available. The United States Government has placed an order amounting to 56 1/2 million dollars with the Republic Aviation Corporation, and the machines are to be built at the firm's works at Farmingdale, N.Y. The span is 36ft. and the wing area 223 sq. ft. With a gross weight of 6,900lb. th; wing loading becomes 31 lb./sq. ft.
Самолёты на фотографии: Republic P-43 Lancer - США - 1940
-
The Martin B-26 bomber is one of the new Americans with several modern features.
Самолёты на фотографии: Martin B-26 Marauder / Type 179 - США - 1940
-
The engine nacelles project well forward of the wing, which is placed slightly above centre of fuselage.
Самолёты на фотографии: Martin B-26 Marauder / Type 179 - США - 1940
-
The tail position, rear turret and unfilleted wing root are noticeable.
Самолёты на фотографии: Martin B-26 Marauder / Type 179 - США - 1940
-
FUTILE CRUELTY: Photograph taken in a Japanese machine bombing Kunming in the Yunan Province. Eighteen twin-engined Mitsubishi bombers took part in the slaughter.
Самолёты на фотографии: Mitsubishi G3M - Япония - 1935
-
Регистрационный номер: K3698 HAWKER-ROLLS: An Audax of No.16 Squadron in 1934. The wireless aerial and message picking-up hook are clearly shown. The Rolls Kestrel engine gave the Audax a speed of 152 m.p.h.
Самолёты на фотографии: Hawker Audax - Великобритания - 1931
-
PIN POINT OR OVERLAP: Aircraftmen fitting a Williamson aerial camera in an Audax belonging to the School of Army Co-operation in 1934.
Самолёты на фотографии: Hawker Audax - Великобритания - 1931
-
MESSAGE PICKING-UP: The strips and posts as seen through the prone bomb-aimer's window of a Hawker Audax.
Самолёты на фотографии: Hawker Audax - Великобритания - 1931
-
HERCULEAN POWER: The Saro Lerwick with its two 1,300 h.p. Bristol Hercules engines is the fastest flying boat in service with the Coastal Command.
Самолёты на фотографии: Saunders-Roe Lerwick / S.36 - Великобритания - 1938
-
MERCHANT MARINE: A large convoy of supply ships escorted by a Short Sunderland which must look out for enemy aircraft and feathers from submarine periscopes.
Самолёты на фотографии: Short Sunderland / S.25 - Великобритания - 1937
-
MEDITERRANEAN MASTERY: A Short Sunderland on patrol over the Grecian Archipelago The Sunderland with its four 1,000 h.p. Bristol Pegasus XXII engines has done valuable work from the North Cape to Alexandria.
Самолёты на фотографии: Short Sunderland / S.25 - Великобритания - 1937
-
COASTAL COMMAND ACQUISITION: The Blackburn Botha, which is already in service as a general reconnaissance and torpedo bomber. It is powered with two 900 h.p. sleeve-valve Bristol Perseus engines. Span is 59ft.; length, 50ft. 11 1/2in.; and height, 18ft. 3in. Points of interest are the streamline power-operated twin gun turret amidships, external bomb racks under wings, twin landing lights in the port leading edge, and the backward-retracting undercarriage.
Самолёты на фотографии: Blackburn Botha / B-26 - Великобритания - 1938
-
ENGLAND'S ICY MOUNTAINS: Three Blackburn Bothas in formation over snow-clad hills.
Самолёты на фотографии: Blackburn Botha / B-26 - Великобритания - 1938
-
The Blackburn Botha has Bristol Perseus sleeve-valve engines.
Самолёты на фотографии: Blackburn Botha / B-26 - Великобритания - 1938
-
Самолёты на фотографии: Blackburn Botha / B-26 - Великобритания - 1938
-
Самолёты на фотографии: Blackburn Botha / B-26 - Великобритания - 1938
-
MISS OTIS REGRETS: A member of the W.R.N.S. delivers a message to a Skua pilot
Самолёты на фотографии: Blackburn Skua / B-24 - Великобритания - 1937
-
ANTIPODEAN: Bristol Beauforts are being made at, among other places, the railway aircraft annexe at Chullora, near Sydney, Australia, where this important work can go on out of the gentle Hermann's reach!
Самолёты на фотографии: Bristol Beaufort - Великобритания - 1938
-
UNLUCKY FOR SOMEONE: Thirteen 18in. torpedoes awaiting installation in Coastal Command Beauforts. This view shows clearly the contra screws and control surfaces.
Самолёты на фотографии: Bristol Beaufort - Великобритания - 1938
-
ITALIAN NIGHTMARE: A formation of Taurus-engined Fairey Albacores with torpedoes aboard.
Самолёты на фотографии: Fairey Albacore - Великобритания - 1938
-
COASTAL COMMAND HUDSONS: During 1940 Coastal Command aircraft of all types flew over 34,000,000 miles in co-operation with the Royal Navy.
Самолёты на фотографии: Lockheed Hudson A-28 / A-29 - США - 1938
-
PACIFIC INTENTIONS: Lockheed Hudsons of the Royal Australian Air Force at Singapore.
Самолёты на фотографии: Lockheed Hudson A-28 / A-29 - США - 1938
-
FOR COASTAL COMMAND, R.A.F. A batch of Lockheed Hudsons being prepared for delivery to Great Britain. The cut-out near the tailplane will have a Boulton Paul power-operated gun turret fitted when the machines arrive in this country.
Самолёты на фотографии: Lockheed Hudson A-28 / A-29 - США - 1938
-
BACK TO FRONT: Italian troops emplaning on a Savoia Marchetti S.M.75 (S.M.82 ???).
Самолёты на фотографии: Savoia-Marchetti / SIAI SM.82 Marsupiale/Canguro - Италия - 1939
-
The Lockheed-Fowler wing flaps are of large area and move backward and downward to ensure a reasonable landing speed though wing loading is high.
Самолёты на фотографии: Lockheed Lodestar L-18/C-59/R5O - США - 1939
-
Регистрационный номер: ZS-ASJ One of America's latest commercial transports, the Lockheed Lodestar, in flight over California before delivery to South African Airways which is re-equipping almost entirely with this type.
Самолёты на фотографии: Lockheed Lodestar L-18/C-59/R5O - США - 1939
-
Fixed slots of the "pillar-box" type are built into the wing tip to guard against wing-dropping near the stall.
Самолёты на фотографии: Lockheed Lodestar L-18/C-59/R5O - США - 1939
-
Tail surfaces, centre section struts and engine bearers being fitted.
Самолёты на фотографии: De Havilland Tiger Moth / D.H.82 - Великобритания - 1931
-
Building the welded metal fuselage and fitting the plywood streamline decking.
Самолёты на фотографии: De Havilland Tiger Moth / D.H.82 - Великобритания - 1931
-
How the moving assembly line passes through the paint spraying room for exterior doping of the fuselage.
Самолёты на фотографии: De Havilland Tiger Moth / D.H.82 - Великобритания - 1931
-
Covering a fuselage with fabric. This work is done by women.
Самолёты на фотографии: De Havilland Tiger Moth / D.H.82 - Великобритания - 1931
-
Регистрационный номер: G-AFCZ After her summer transatlantic work, Clare was completely overhauled for the hard days of winter.
Самолёты на фотографии: Short Empire / S.23 - Великобритания - 1936
-
A Stratoliner above Lake Mead, the world's largest reservoir. The Boulder Dam is below the aeroplane, in the foreground.
Самолёты на фотографии: Boeing Boeing 307 Stratoliner - США - 1938
-
"OVERWEATHER FLYING." A Boeing Stratoliner above the clouds.
Самолёты на фотографии: Boeing Boeing 307 Stratoliner - США - 1938
-
"INFLATING" THE STRATOLINER. A final test of the cabin by compressed air before a high-altitude flight. Pressures are being checked by the manometers on the board.
Самолёты на фотографии: Boeing Boeing 307 Stratoliner - США - 1938
-
ON MEDIUM PATROL: A flight of No. 26 (Army - Co-operation) Squadron over the Yorkshire Moors.
"POST WORLD WAR I": Three Armstrong-Whitworth Atlasses of No.26 (A.C.) Squadron in 1933. Wireless was placed just aft of the rear gunner.Самолёты на фотографии: Armstrong Whitworth Atlas / Ajax - Великобритания - 1925
-
TESTING WIRELESS SETS: Three different sets can be carried on the "Atlas" according to whether its duty is artillery observation, close reconnaissance, or medium reconnaissance.
Самолёты на фотографии: Armstrong Whitworth Atlas / Ajax - Великобритания - 1925
-
A WAKEFIELD MEMORY. Standing in front of the aeroplane "Youth of Britain," on which Sir Alan Cobham toured the country in 1929, are, left to right, Capt. G. de Havilland, Sir Alan Cobham, Lord Wakefield, Lady Cobham and Sir Sefton Brancker.
Самолёты на фотографии: De Havilland Giant Moth / D.H.61 - Великобритания - 1927
-
The late Collyns Pizey, "a dear soul and a good pilot."
Самолёты на фотографии: Bristol Type T - Великобритания - 1911
-
DESIGNER AND PILOT, TOO. Mr. E. C. Gordon-England in a Bristol box kite, Circa 1911.
Самолёты на фотографии: Bristol Type T - Великобритания - 1911
-
The Howard Wright biplane on which the author made his first passenger flight with Lieut. Watkins. This picture actually shows Mr. T. O. M. Sopwith in the pilot's seat.
Самолёты на фотографии: Howard Wright No.2 biplane - Великобритания - 1910
-
Miss Amy Johnson, of Hull, who left Croydon on May 5 for Australia, piloting a D.H. "Gipsy-Moth." Miss Johnson, who is the only woman to hold an Air Ministry ground engineer's licence, hopes to beat Bert Hinkler's record of 15 1/2 days for the journey.
A Flight photograph of Amy Johnson taken in the days when she was a member of the London Aeroplane Club at Stag Lane.Самолёты на фотографии: De Havilland Gipsy Moth / Moth X - Великобритания - 1928
-
Регистрационный номер: G-EANW, C7185 SINGLE BAY B.E.: The top wing of the B.E.2.e. had a pronounced overhang and only a single pair of interplane struts on each side.
Самолёты на фотографии: RAF B.E.2e - Великобритания - 1916
-
Регистрационный номер: T0222 [2] PRESSURE CABIN RESEARCH. A General Aircraft Monospar has an auxiliary engine in the nose for driving the cabin supercharger.
Самолёты на фотографии: General Aircraft GAL.41 - Великобритания - 1939
-
Регистрационный номер: T0222 [2] The cabin door of the Monospar is of special design to provide airtightness.
Another view of T-0222 circa September 20, 1940.Самолёты на фотографии: General Aircraft GAL.41 - Великобритания - 1939
Статьи
- Flight
- Flight Advertisements
